12x12 Foot pad with Bolt #7821
$95.36
12 by 12 inch foot pad, EQ Systems part 7821
The foot pad is the plate at the bottom of a hydraulic jack leg that carries the load into the ground. This is the 12 by 12 inch replacement pad, supplied with its bolt. It is the version for jack legs without a leg switch.
Jacks this foot pad fits
- SL 18 jack, part 7134, 3 3/8 inch body plate mount, body length 22 3/4", plate position 1", rod diameter 2"
- SL 24 jack, part 7923, 3 3/8 inch body plate mount, body length 29 1/2", plate position 8 1/2", rod diameter 2". Body length was 29 inches before June 2023.
- SL 24 jack, part 7848, 3 3/8 inch body plate mount, body length 29 1/2", plate position 14 1/2", rod diameter 2". Body length was 29 inches before June 2023.
Those jacks are rated at 17.5k lifting capacity each.
Identifying the right pad
Measure your existing pad before ordering. An octagon pad is measured across the flats and a round pad across the diameter. Then confirm the jack itself: the body length is the fixed outer body of the jack, measured with the jack retracted, and the plate or bracket position is measured from the closed end of the body, positive toward the foot and negative past the closed end. Every EQ Systems jack, its body length, and the foot that belongs to it are listed in the chart below.
A worn, bent or missing foot pad is worth replacing promptly on a system that uses leg switches. The switch is operated by the foot leaving and returning to the stowed position, so a missing foot will not operate the switch at all, a bent or distorted foot may not activate it properly, and a foot bent upward can damage or destroy the switch.
